• Flat bed parallel .0001" per inch
• Greater precision clamping with deflection less than .0015"

FEATURES

• Cast parts are made from highest grade ductile iron.
• The vise body with flame-hardened bed provides solid work support.
• Screws are hardened and ground. and then totally enclosed for years of productivity.
• Hardened spherical segment eliminates movable jaw tilt. Each pound of force horizontally produces one-half pound of force vertically.
• Jaw plates are manufactured of tool steel. which is ground and hardened.
• Vises have a roller bearing thrust collar, which reduces friction and significantly increases holding power.
• 4-position of jaw plates allows extra capacity in outside position.
• Precision ground surfaces provided on top and bottom of vise bed and swivel base, also on tops of both jaws
• Swivel base is graduated to 180° in 1° increments.
• Universal crank handle

Any specifications may be changed without notice.
